ASUS TUF GAMING B760-PLUS WIFI LGA1700 (RAPTOR LAKE) 4DDR5 HDMI+DP M.2 ATX Motherboard
2 595,02 kr
2 430,08 kr
Save 6,36%
eller med
Betala på 3 månader med
Tax included
För offertförfrågningar för stora kvantiteter, skriv till info@ewooow.it och ange postnummer
100% SÄKER BETALNING.
Kunden garanteras system för förebyggande av bedrägerier
TA EMOT DIN BESTÄLLNING INOM 3-5 ARBETSDAGAR!
Snabb leverans direkt hem till dig. Du kan spåra din försändelse med den angivna koden.
2 ÅRS GARANTI
Alla våra produkter är originalprodukter och levereras med två års garanti i hela Europa
MB ASUS TUF GAMING B760-PLUS WIFI LGA1700 (RAPTOR LAKE) 4DDR4 HDMI+DP M2 ATX
| BIOS | |
|---|---|
| BIOS memory size | 128 |
| BIOS type | UEFI AMI |
| Features | |
| Motherboard chipset | Intel B760 |
| Component for | PC |
| Motherboard form factor | ATX |
| Audio output channels | 7.1 |
| Windows operating systems supported | Windows 10, Windows 11 |
| Cooling type | Passive |
| Motherboard chipset family | Intel |
| Power source type | ATX |
| Networking | |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Packaging content | |
| Cables included | SATA |
| Storage controllers | |
| RAID levels | 0, 1, 5, 10 |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 4 |
| Supported storage drive interfaces | M.2, PCI Express 3.0, PCI Express 5.0, SATA III |
| Number of storage devices supported | 7 |
| RAID support | Yes |
| Packaging data | |
| Package height | 53 |
| Package width | 328 |
| Package weight | 1160 |
| Package depth | 266 |
| Weight & dimensions | |
| Depth | 244 |
| Width | 305 |
| Graphics | |
| Parallel processing technology support | Not supported |
| Internal I/O | |
| Thunderbolt ports | 1 |
| 12V power connector | Yes |
| Front panel connector | Yes |
| RGB LED pin header | Yes |
| Number of COM connectors | 1 |
| Number of chassis fan connectors | 3 |
| CPU fan connector | Yes |
| ATX power connector (24-pin) | Yes |
| S/PDIF out connector | Yes |
| TPM connector | Yes |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| EPS power connector (8-Pin) | Yes |
| Front panel audio connector | Yes |
| USB 2.0 connectors | 2 |
| Number of SATA III connectors | 4 |
| USB 3.0 connectors | 2 |
| Memory | |
| Number of memory slots | 4 |
| Maximum internal memory | 128 |
| Non-ECC | Yes |
| Supported memory types | DDR5-SDRAM |
| Memory channels support | Dual-channel |
| Unbuffered memory | Yes |
| Memory slot type | DIMM |
| Supported memory clock speeds (max) | 5066 |
| Networking | |
| Bluetooth | Yes |
| Wi-Fi | Yes |
| Wireless LAN standards | 802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Bluetooth version | 5.2 |
| Ethernet LAN | Yes |
| Rear panel I/O ports | |
| HDMI version | 2.1 |
| USB 3.1 (3.1 Gen 2) Type-A ports quantity | 2 |
| DisplayPort version | 1.4 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| DisplayPorts quantity | 1 |
| USB 2.0 ports quantity | 2 |
| Line-in | Yes |
| Processor | |
| Processor manufacturer | Intel |
| Supported processor sockets | LGA 1700 |
| Compatible processors | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7 |
| Maximum SMP processors | 1 |
| Processor socket | LGA 1700 |
| Expansion slots | |
| Number of M.2 (M) slots | 3 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| PCI Express x1 (Gen 3.x) slots | 2 |
