QNAP TS-453E-8G 4-Bay 2.5GbE NAS with 8GB RAM and HDMI

TS-453E

Dual 2.5GbE, 8GB RAM, and long-term availability

The TS-453E features 2.5GbE connectivity, 8GB RAM, and M.2 slots for NVMe SSD cache to deliver high performance for applications such as surveillance systems, virtual machines, file servers, or backup servers. Two HDMI outputs also provide direct multimedia playback and robust surveillance monitoring. QNAP offers long-term availability and support for the TS-453E, making it an ideal choice for businesses that require the deployment of perfect NAS models in various locations.

Dual 2.5GbE ports
2.5 times faster network speed with existing CAT5e cables supporting port trunking to deliver up to 5 Gbps.

Dual PCIe M.2 2280 slots
Achieve excellent NAS performance by installing M.2 2280 NVMe PCIe SSDs (sold separately) or Edge TPU.

8GB built-in RAM
Optimized system performance and multitasking thanks to 8GB of RAM.

Long-term model
The TS-453E will be available and supported by QNAP for an extended period, until 2029.

Dual HDMI output
Dual-screen extension can be used for surveillance or high-resolution 4K video playback.

Expandable storage capacity
Supports USB expansion enclosures (refer to the compatibility list).

TECHNICAL FEATURES

• Hard Disk Bus: SATA
• Placement: Office
• RAID Support: 1
• IP Support: IPv4/IPv6
• File Systems Type: EXT4 (internal) , EXT4, EXT3, FAT, NTFS, HFS+ (External)
• CPU Type: Intel
• Operating System: QNAP QTS
• Flash Memory: 4000.0000
• DDRAM Memory: 8000.0000
• Maximum CIFS users: 1500.0000
• Maximum FTP users: 1024.0000

CONNECTIVITY

• LAN Speed: 100/1000/2500
• Number of USB ports: 4.0000
• Number of LAN ports: 2.0000
• LAN port connectors: Gigabit Ethernet
• LAN Compliance:

  2 x 2.5 Gigabit Ethernet ports (2.5G/1G/100M/10M)


• Console Port: 0

POWER SUPPLY

• Redundant Power Supply: 0
• Power Supply: AC
• Power Supply Voltage: 100/240
• Power Supply Frequency: N/A
• Power Supply Power Consumption: 33.8800

PHYSICAL CHARACTERISTICS

• Chassis Format: Tower
• Chassis Color: Black
• LEDs:

  Power/Status, LAN, USB, HDD1-4


• Maximum Height: 177.0000
• Maximum Width: 180.0000
• Maximum Depth: 235.0000
• Weight: 4300.0000

PROTOCOLS

• Iscsi: 1
• AFP: 1
• Cifs: 1
• SMB: 1
• NFS: 1
• Http: 1
• Https: 1
• FTP: 1
• Ftps: 1
• Rsync: 1

STORAGE

• Total Bays: 4.0000
• Total Included Disk Capacity: 0.0000
• Number of Included Disks: 0.0000
• Storage Unit: SATA
• Enclosures Support: 1
• Disk slot size: 2.5''/3.5''

RAID LEVELS

• RAID 1 (Mirroring): 1
• Raid 5: 1
• Raid 6: 1
• Jbod: 1
• RAID 0 (Striping): 1

WIRELESS EXTENSIONS

• Wireless Extensions: 0
• Wireless Security: 0

COMPLIANCE

• Declaration of Conformity:

  CE

PACKAGE

• Cables Included:

  Ethernet cable x 1
  Power cord x 1
  AC Adapter


• Software:

  .

• Manuals:

  Quick Installation Guide (QIG)


• Various Kits and Accessories:

  Flat head screw (for M.2 SSD) x 2
  Flat head screw (for 3.5" HDD) x 16
  Flat head screw (for 2.5" HDD) x 12
  Drive tray keys x 2
