BIOSTAR Z690MX2-E D4 LGA1700 mATX Motherboard
116,41 €
106,79 €
Enregistrer 8,27%
Paga en 3 meses con
Tax included
Para solicitudes de cotización de grandes cantidades, escriba a info@ewooow.it especificando el código postal
PAGO 100% SEGURO.
El cliente está garantizado por el sistema de prevención de fraude
¡RECIBE TU PEDIDO EN 3-5 DÍAS LABORABLES!
Entrega rápida directamente a tu hogar. Puedes rastrear el envío con el código proporcionado.
2 AÑOS DE GARANTÍA
Todos nuestros productos son originales y tienen dos años de garantía en toda Europa
MB BIOSTAR Z690MX2-E D4 LGA1700 (ALDER LAKE) 2DDR4 HDMI+DVI+VGA PCIE, M2, mATX - Z690MX2-E D4
| BIOS | |
|---|---|
| BIOS Type | UEFI |
| Features | |
| Audio chip | Realtek ALC897 |
| Motherboard chipset | Intel Z690 |
| Component for | PC |
| Motherboard form factor | micro ATX |
| Audio system | 7.1 |
| Windows operating system supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | Intel |
| PC health monitoring | CPU, Fan, Temperature |
| Packaging content | |
| Software | BullGuard |
| Drivers included | Yes |
| Cables included | SATA |
| Storage controllers | |
| RAID levels | 0, 1, 5, 10 |
| Supported storage drive types | HDD & SSD |
| Number of hard drives supported | 5 |
| Supported storage drive interfaces | M.2, SATA III |
| RAID support | Yes |
| Weight & dimensions | |
| Depth | 236 |
| Width | 208 |
| Internal I/O | |
| USB 3.1 (3.1 Gen 2) connectors | 0 |
| Front panel connector | Yes |
| Number of COM connectors | 1 |
| Number of chassis fan connectors | 1 |
| CPU fan connector | Yes |
| ATX power connector (24-pin) | Yes |
| TPM connector | Yes |
| EPS power connector (8-Pin) | Yes |
| USB 2.0 connectors | 4 |
| Number of SATA 3 connectors | 4 |
| USB 3.0 connectors | 2 |
| Memory | |
| Number of memory slots | 2 |
| Maximum supported memory | 64 |
| Supported memory clock speeds | 1866,2133,2400,2666,2933,3200,3600,3800,4000,4400 |
| Supported memory types | DDR4-SDRAM |
| Memory channels support | Dual-channel |
| Memory slot type | DIMM |
| ECC | Non-ECC |
| Networking | |
| Wi-Fi | No |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Ethernet LAN | Yes |
| LAN controller | Realtek RTL8125B |
| Rear panel I/O ports | |
| USB 3.1 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.1 (3.1 Gen 2) Type-C ports quantity | 0 |
| USB 3.0 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports quantity | 1 |
| USB 2.0 ports quantity | 4 |
| PS/2 ports quantity | 1 |
| Processor | |
| Processor manufacturer | Intel |
| Compatible processors | Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 12th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 12th Gen, Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen |
| Processor socket | LGA 1700 |
| Expansion slots | |
| Number of M.2 (M) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x1 (Gen 3.x) slots | 1 |
