ASUS TUF GAMING B860-PLUS WIFI Motherboard
€289.45
€269.66
Save 6.84%
Pay in 3 months with
Tax included
For quotation requests for large quantities, write to info@ewooow.it specifying the zip code
100% SECURE PAYMENT.
The customer is guaranteed fraud prevention system
RECEIVE YOUR ORDER WITHIN 3-5 WORKING DAYS!
Fast delivery straight to your home. You can track your shipment with the provided code.
2 YEARS WARRANTY
All our products are original and have a two-year guarantee throughout Europe
MB ASUS TUF GAMING B860-PLUS WIFI LGA B860 (ARROW LAKE) 4DDR5 HDMI+DP+TYPE-C T 3*M2 WIFI7 PCIE 4.0 ATX
| BIOS | |
|---|---|
| BIOS memory size | 256 |
| BIOS type | UEFI AMI |
| Features | |
| Motherboard chipset | Intel B860 |
| Component for | PC |
| Motherboard form factor | ATX |
| Audio system | 7.1 |
| Windows operating system supported | Windows 11 |
| Motherboard chipset family | Intel |
| Networking | |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| Packaging content | |
| Cables included | SATA |
| Screws included | Yes |
| Antenna included | Yes |
| Storage controllers | |
| RAID levels | 0, 1, 5, 10 |
| Supported storage drive types | HDD & SSD |
| Number of hard drives supported | 4 |
| Supported storage drive interfaces | M.2, SATA III |
| Number of storage devices supported | 7 |
| RAID support | Yes |
| Packaging data | |
| Package height | 68 |
| Package width | 353 |
| Package weight | 2097 |
| Package depth | 273 |
| Weight & dimensions | |
| Depth | 244 |
| Width | 305 |
| Graphics | |
| Parallel processing technology support | Not supported |
| Internal I/O | |
| Thunderbolt ports | 1 |
| USB 3.1 (3.1 Gen 2) connectors | 1 |
| 12V power connector | Yes |
| Front panel connector | Yes |
| Number of COM connectors | 1 |
| Number of chassis fan connectors | 4 |
| CPU fan connector | Yes |
| ATX power connector (24-pin) | Yes |
| S/PDIF out connector | Yes |
| Front panel audio connector | Yes |
| Chassis intrusion connector | Yes |
| USB 2.0 connectors | 1 |
| Number of SATA 3 connectors | 4 |
| USB 3.0 connectors | 1 |
| Memory | |
| Number of memory slots | 4 |
| Maximum internal memory | 256 |
| Supported memory types | DDR5-SDRAM |
| Memory channels support | Dual-channel |
| Unbuffered memory | Yes |
| Memory slots type | DIMM |
| ECC | Non-ECC |
| Networking | |
| Bluetooth | Yes |
| WLAN connection | Yes |
| Wireless LAN type | Wi-Fi 7 (802.11be) |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Bluetooth version | 5.4 |
| Ethernet LAN | Yes |
| Rear panel I/O ports | |
| USB 3.1 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.1 (3.1 Gen 2) Type-C ports quantity | 0 |
| USB 3.0 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 0 |
| VGA (D-Sub) ports quantity | 0 |
| Ethernet LAN (RJ-45) ports quantity | 1 |
| DisplayPorts quantity | 1 |
| USB 2.0 ports quantity | 2 |
| WiFi-AP antenna jack | 1 |
| S/PDIF out port | Yes |
| Processor | |
| Processor manufacturer | Intel |
| Supported processor sockets | LGA 1851 |
| Compatible processors | Intel Core Ultra (Series 2) |
| Processor socket | LGA 1851 (Socket V1) |
| Expansion slots | |
| Number of M.2 (M) slots | 3 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| PCI Express x1 (Gen 4.x) slots | 1 |
| M.2 Key M max size first | 2280 |
| M.2 Key M max size second | 2280 |
| M.2 Key M max size third | 2280 |
| PCI Express M.2 first max generation | 5.0 |
| PCI Express M.2 second max generation | 4.0 |
| PCI Express M.2 third max generation | 4.0 |
