ASUS PRIME Z790M-PLUS LGA1700 mATX Motherboard
€264.70
€247.15
Save 6.63%
Pay in 3 months with
Tax included
For quotation requests for large quantities, write to info@ewooow.it specifying the zip code
100% SECURE PAYMENT.
The customer is guaranteed fraud prevention system
RECEIVE YOUR ORDER WITHIN 3-5 WORKING DAYS!
Fast delivery straight to your home. You can track your shipment with the provided code.
2 YEARS WARRANTY
All our products are original and have a two-year guarantee throughout Europe
MB ASUS PRIME Z790M-PLUS LGA1700 (RAPTOR/ALDER LAKE) 4DDR5 HDMI+DP 3*M2 mATX
| BIOS | |
|---|---|
| BIOS memory size | 192 |
| BIOS type | UEFI AMI |
| Features | |
| Motherboard chipset | Intel Z790 |
| Component for | PC |
| Motherboard form factor | micro ATX |
| Audio system | 7.1 |
| Windows operating system supported | Windows 10, Windows 11 |
| Motherboard chipset family | Intel |
| Power source type | ATX |
| Packaging content | |
| Software | ASUS Exclusive Software Armoury Crate - Aura Sync - Fan Xpert 4 (with AI Cooling II) - Power Saving AI Suite 3 - TurboV EVO - DIGI+ VRM - PC Cleaner ASUS CPU-Z Norton 360 Deluxe (60 Days Free Trial) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode |
| Cables included | SATA |
| Storage controllers | |
| RAID levels | 0, 1, 5, 10 |
| Supported storage drive types | HDD & SSD |
| Number of hard drives supported | 3 |
| Supported storage drive interfaces | M.2, PCI Express 4.0, SATA |
| Number of storage devices supported | 4 |
| RAID support | Yes |
| Weight & dimensions | |
| Depth | 244 |
| Width | 244 |
| Internal I/O | |
| Serial port headers | 1 |
| Thunderbolt ports | 1 |
| 12V power connector | Yes |
| Audio connector | Yes |
| RGB LED connector | Yes |
| Number of SATA connectors | 4 |
| Number of COM connectors | 1 |
| Number of chassis fan connectors | 3 |
| CPU fan connector | Yes |
| ATX power connector (24-pin) | Yes |
| Fan power connector | Yes |
| S/PDIF out connector | Yes |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| EPS power connector (8-Pin) | Yes |
| USB 2.0 connectors | 2 |
| USB 3.0 connectors | 2 |
| Memory | |
| Number of memory slots | 4 |
| Maximum internal memory | 128 |
| Non-ECC | Yes |
| Supported memory speeds | 4800,5000,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200 |
| Supported memory types | DDR5-SDRAM |
| Memory channels support | Dual-channel |
| Unbuffered memory | Yes |
| Memory slots type | DIMM |
| Networking | |
| Wi-Fi | No |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Rear panel I/O ports | |
| HDMI version | 2.0 |
| USB 3.1 (3.1 Gen 2) Type-A ports quantity | 1 |
| DisplayPort version | 1.4 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB connector type | USB Type-A |
| USB 3.0 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| Microphone in | Yes |
| Ethernet LAN (RJ-45) ports quantity | 1 |
| COM ports quantity | 1 |
| Headphone outputs | 1 |
| DisplayPorts quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Line-in | Yes |
| Processor | |
| Processor manufacturer | Intel |
| Compatible processors | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold |
| Processor socket | LGA 1700 |
| Expansion slots | |
| Number of M.2 (M) slots | 3 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| PCI Express x1 (Gen 4.x) slots | 2 |
