ASUS ROG STRIX B760-A GAMING WIFI LGA1700 (RAPTOR LAKE) 4DDR5 HDMI+DP M.2 ATX Motherboard
€290.83
€270.47
Save 7%
Pay in 3 months with
Tax included
For quotation requests for large quantities, write to info@ewooow.it specifying the zip code
100% SECURE PAYMENT.
The customer is guaranteed fraud prevention system
RECEIVE YOUR ORDER WITHIN 3-5 WORKING DAYS!
Fast delivery straight to your home. You can track your shipment with the provided code.
2 YEARS WARRANTY
All our products are original and have a two-year guarantee throughout Europe
MB ASUS PROG STRIX B760-A GAMING WIFI D4 LGA1700 (RAPTOR LAKE) 4DDR4 HDMI+DP M2 ATX
| BIOS | |
|---|---|
| BIOS memory size | 256 |
| BIOS type | UEFI AMI |
| Features | |
| Audio chip | Realtek ALC4080 |
| Motherboard chipset | Intel B760 |
| Component for | PC |
| Motherboard form factor | ATX |
| Audio system | 7.1 |
| Windows operating system supported | Windows 10 x64, Windows 11 |
| Motherboard chipset family | Intel |
| Networking | |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Packaging content | |
| Cables included | SATA |
| Storage controllers | |
| RAID levels | 0, 1, 5, 10 |
| Supported storage drive types | HDD & SSD |
| Number of hard drives supported | 4 |
| Supported storage drive interfaces | M.2, SATA III |
| Number of storage devices supported | 7 |
| RAID support | Yes |
| Dimensions and weight | |
| Depth | 244 |
| Width | 305 |
| Graphics | |
| Parallel processing technology | Not supported |
| Internal I/O | |
| Thunderbolt ports | 1 |
| USB 3.1 (3.1 Gen 2) connectors | 1 |
| 12V power connector | Yes |
| RGB LED connector | Yes |
| Number of chassis fan connectors | 4 |
| CPU fan connector | Yes |
| ATX power connector (24-pin) | Yes |
| S/PDIF out connector | Yes |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| EPS power connector (8-Pin) | Yes |
| Front panel audio connector | Yes |
| USB 2.0 connectors | 1 |
| Number of SATA III connectors | 4 |
| USB 3.0 connectors | 1 |
| Memory | |
| Number of memory slots | 4 |
| Maximum supported memory | 128 |
| Non-ECC | Yes |
| Supported memory speeds | 7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5400,5200,5000,4800 |
| Supported memory types | DDR5-SDRAM |
| Memory channels support | Dual-channel |
| Unbuffered memory | Yes |
| Memory slot type | DIMM |
| Supported memory clock speed (max) | 7800 |
| Networking | |
| Bluetooth | Yes |
| WLAN connection | Yes |
| Wireless LAN type | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Bluetooth version | 5.3 |
| Ethernet LAN connection | Yes |
| Rear panel I/O ports | |
| HDMI version | 2.1 |
| USB 3.1 (3.1 Gen 2) Type-A ports quantity | 1 |
| DisplayPort version | 1.4 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.0 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| Microphone in | Yes |
| Ethernet LAN (RJ-45) ports quantity | 1 |
| Speaker / headphone / line-out jack | 1 |
| DisplayPorts quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Line-in | Yes |
| Processor | |
| Processor manufacturer | Intel |
| Supported processor sockets | LGA 1700 |
| Compatible processors | Intel® Celeron®, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
| Processor socket | LGA 1700 |
| Expansion slots | |
| Number of M.2 (M) slots | 3 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 3.x) slots | 1 |
