WHITE USB 2.0 SMART CARD READER - LKCARD02

WHITE USB 2.0 SMART CARD READER - LKCARD02

€19.88 €17.89
Save 10%

Pay in 3 months with Klarna

Tax included
Extra secure payment logo 2

For quotation requests for large quantities, write to info@ewooow.it specifying the zip code

  100% SECURE PAYMENT.

The customer is guaranteed fraud prevention system

  RECEIVE YOUR ORDER WITHIN 3-5 WORKING DAYS!

Fast delivery straight to your home. You can track your shipment with the provided code.

  2 YEARS WARRANTY

All our products are original and have a two-year guarantee throughout Europe

Link Accessori LKCARD02 Interno USB 2.0 Bianco lettore di card readers

Descrizione

USB 2.0 single-slot reader for all common smart cards in use. Connects to the USB port. With very complete performance, no need to be powered, and small in size, it can be placed where you want without creating clutter. Elegant design with non-slip pads.
It supports the standards in use in smart cards, such as ISO7816 (the standard for IC cards, PC/SC 2.0 for the Windows standard, Microsoft WHQL, EMV for Europay MasterCard, Visa standard and USB-IF CCID standard.
It can be used with devices such as ATMs, POS terminals, public telephones, E-Commerce, Accountants, payment systems, law firms, public offices, etc.
Supports EMV Level 1 specifications
Supports ISO7816 & EMV 2 2000 Level 1 specifications
Supports PC Smart Card industry standard - PC/SC 2.0
Supports Microsoft Smart Card for Windows
Compliant with Microsoft WHQL USB Smart Card Reader
Compliant with US Federal Information Processing Standards (FIPS) Publication 201 for smart card reader interoperability requirements.
Supports T0, T1, 2-wire SLE 4432/42 (S=10), 3-wire SLE 4418/28 (S=9), I2C (S=8) protocols.
Supports I2C memory cards, SLE4418, SLE4428, SLE4432, SLE4442, SLE4436, SLE5536, SLE6636, AT88SC1608, AT45D041, 4404, Icard, Athena card and AT45DB041 card via external EEPROM
Supports ISO7816 Class A, B and C (5V/3V/1.8V), ID-1 (full-size) cards.
Integrated PLL for USB and Smart Card clock requirements
Supports EEPROM for customizing USB descriptors (PID/VID/iManufacturer/iProduct/Serial Number), Direct Web Page Link, and memory card access module
EEPROM programmable via USB interface
Supports software update for memory card module.
Supports Direct Web Page Link via configuration in external EEPROM.
Supports short and extended APDU.
Compatible with Microsoft USB-CCID drivers.
Supports remote wake up via card insertion/removal.
Supports USB selective suspend.
Supports power saving mode (Using a pin to choose between normal/PWR mode)
No external power supply required, powered via bus.
Dimensions 83.6 x 65.1 x 9.5 mm.
Weight 0.09
Material: ABS


Dettagli tecnici
Colore del prodotto White
Posizionamento supportato Indoor
Materiale della scocca Acrilonitrile butadiene stirene (ABS)
Tipo di imballo Blister
Requisiti di sistema
Sistema operativo Windows supportato Si
Connettività
Interfaccia USB 2.0
Dimensioni e peso
Altezza 9.5 mm
Larghezza 83.6 mm
Profondità 65.1 mm
Peso 90 g
Gestione energetica
Alimentazione USB Si
Certificati di sicurezza
Conformità RoHS Si
Link
CMT_LKCARD02
8028400064509
