Power supply TooQ TQEP-500S-INT ATX 500 W RoHS

The TooQ TQEP-500S-INT power supply from the Ecopower II series offers an efficient and reliable solution for ATX-format computers requiring stable and secure power delivery. With a total output of 500 W, it is designed for desktop systems that need solid energy supply, supporting standard setups and moderate-consumption components. This model features active power factor correction (Active PFC, PF > 0.99), ensuring over 78% efficiency and reducing heat generation, which helps extend the lifespan of both the power supply and connected components. It is equipped with a 12 cm fan engineered for quiet operation and constant cooling, keeping noise levels as low as 20 dB—ideal for work or leisure environments where low sound is important. For connectivity, it includes a 24/20-pin ATX connector for the motherboard, 1x ATX 12V 8-4 pin for CPU, 4 SATA connectors for hard drives or SSDs, and 2 Molex 4-pin connectors for peripherals, allowing versatile installation compatible with most current configurations. The chassis features a silver color design and a compact size of 150 x 140 x 86 mm, making integration into the PC case easy. For protection, it incorporates multiple advanced electronic systems against overcurrent, overvoltage, overpower, overheating, short circuit, and undervoltage, ensuring both the connected hardware and the power supply itself are safeguarded from electrical incidents. This unit, which also has RoHS sustainability certification, operates within a 115-230 V input voltage range for greater adaptability. It includes a user manual for easy installation and meets the quality standards associated with the TooQ range. In summary, the TooQ TQEP-500S-INT is a robust and quiet choice for those seeking energy efficiency and multiple protections for their ATX PC power supply.

• Type: Power supply
• Power supply:
  • Electric Network
  • ATX
• Approx. dimensions: 14 x 15 x 8,6 cm
• Connections:
  • ATX 24-pin x 1
  • ATX 12V x 1 x 1
  • Molex 4-pin
  • CPU 4+4 PIN
  • SATA
  • ATX 24-pin
  • 24-pin ATX x 1
• Cable length: 1,2 m
• Type of plug: Plug EU
• Format: ATX
• Product with plug: Yes
• Recommended use:
  • Desktop PC
  • PC
• Depth: 140 mm
• Width:
  • 150 mm
  • 15 cm
• Version ATX: 1.3
• Colour: Silver
• Material: Plastic
• Power: 500 W
• Form factor: ATX
• Voltage:
  • 220 V
  • 115 - 230 V
• Ventilator:
  • 1
  • 12 cm
• Approx. weight: 1 kg
• Compatible: ATX
• Includes: Instruction manual
• Certificate: RoHS
• Noise level: 20 dB
• Connectors: SATA x 4

TooQ TQEP-500S-INT. Total power: 500 W, AC input voltage: 115 - 230 V, Power Factor Correction (PFC) type: Active. Motherboard power connector: 24-pin ATX. Purpose: PC, Power supply unit (PSU) form factor: ATX, Noise level: 20 dB. Product colour: Silver, Fan diameter: 12 cm, Number of fans: 1 fan(s). Width: 150 mm, Depth: 140 mm, Height: 86 mm

• Total power: 500 W
• AC input voltage: 115 - 230 V
• Power factor: 0.99
• Power Factor Correction (PFC) type: Active
• Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
• Motherboard power connector: 24-pin ATX
• Peripheral (Molex) power connectors (4-pin): 2
• Number of SATA power connectors: 4
• Purpose: PC
• Power supply unit (PSU) form factor: ATX
• ATX version: 1.3
• Noise level: 20 dB
• Product colour: Silver
• Fan diameter: 12 cm
• Number of fans: 1 fan(s)
• Width: 150 mm
• Depth: 140 mm
• Height: 86 mm
• Sustainability certificates: RoHS
• Manual: Y
