Motherboard Gigabyte Z790 EAGLE AX LGA 1700

The Gigabyte Z790 EAGLE AX motherboard is designed for high‑performance systems based on Intel processors with LGA 1700 socket, supporting from Intel® Celeron® up to latest‑generation Intel® Core™ i3, i5, i7 and i9. It integrates the advanced Intel Z790 Express chipset, enabling overclocking, power management and Z‑series connectivity features, and supports DDR5‑SDRAM in dual‑channel configuration with 4 DIMM slots, up to 192 GB and speeds up to 7600 MHz, including unbuffered modules with and without ECC, making it suitable for intensive use and semi‑professional setups. The ATX form factor (305 x 244 mm) ensures compatibility with most standard towers, while the storage subsystem combines 3 M.2 sockets and 4 SATA III ports, with support for HDD and SSD and RAID 0/1/5/10 configuration, optimising capacity, performance and data redundancy. For graphics and expansion cards it includes PCI Express x16 Gen 5.0 and Gen 4.0 slots for latest‑generation GPUs plus PCIe x1 Gen 3.x for extra cards, and offers integrated display outputs via HDMI 2.1 and DisplayPort 1.2 with maximum resolution of 4096 x 2304 pixels, ideal when using processor integrated graphics. Network connectivity is complete thanks to the 2.5 GbE Ethernet (RJ‑45) port and the Intel Wi‑Fi 6E AX211 wireless module with dual antenna, adding support for Wi‑Fi 6E (802.11ax) and previous standards, plus Bluetooth 5.3 for peripherals and mobile devices. The rear I/O panel offers a balanced mix of USB 3.2 Gen 2x2 Type‑C, several USB 3.2 Gen 1 and Gen 2 Type‑A and USB 2.0 ports, while the board includes internal headers for front panel, audio and Thunderbolt, simplifying advanced builds and cases with extensive connectivity. Audio is handled by the Realtek ALC897 codec with 7.1‑channel audio, outputs for headphones, microphone and S/PDIF, suitable for gaming, multimedia or basic professional use. Power is provided via a 24‑pin ATX connector, dual auxiliary power connectors, an 8‑pin EPS connector for CPU and multiple fan headers, plus monitoring of fan, temperature, voltage and liquid cooling for precise system control. Firmware is based on UEFI AMI with 256 MB BIOS, includes a jumper and Clear CMOS button, and is compatible with Windows 10 x64 and Windows 11 x64, and comes with accessories such as SATA cables, Wi‑Fi antennas and a pre‑installed CR2032 battery. Overall, the Gigabyte Z790 EAGLE AX is a modern, versatile ATX motherboard for gaming PCs, content creation and high‑performance systems requiring wide connectivity and support for next‑generation hardware.

• Type:
  • Motherboard
  • PCI Express 3.0
  • ATX
  • UEFI
• Connections:
  • USB
  • USB-C
  • RJ45
  • Jack 3.5 mm
  • DisplayPort
  • SATA
  • Ethernet LAN
  • PCI Express 3.0
  • USB 3.2
  • HDMI 2.1
  • M.2
  • DisplayPort 1.2
  • HDMI x 1
  • 2 x USB 2.0
  • Microphone
  • SATA x 4
  • PS/2 x 1
  • DIMM x 4
  • M.2 x 3
  • Thunderbolt x 2
  • HDMI 2.1 x 1
  • DIMM
  • 4 x USB 3.2 Gen 1 (3.1 Gen 1)
  • USB-A - USB-C
  • DisplayPort x 1
  • USB 3.2 x 1
  • RJ45 x 1
• Depth: 244 mm
• Chipset:
  • Intel Z790 Express
  • INTEL Z790
• USB 2.0: 2
• Power supply: ATX
• Bluetooth: Yes
• Colour: Brown
• Connectivity:
  • Bluetooth
  • Wi-Fi
  • Ethernet LAN
  • Wi-Fi 6 GHz
  • Bluetooth 5.3
  • Wi-Fi 6E ghz
• Form factor: ATX
• Interface: Gigabit Ethernet
• Battery: CR2032
• Memory: 256 MB
• Number of memory slots: 4
• Batteries included: Yes
• Speakers: 7.1
• Compatible:
  • HDD/SSD
  • PC
• Connectors: SATA x 4
• Width: 30,5 cm
• Includes: SATA
• Resolution: 4096 x 2304 px
• Sound: Realtek ALC897
• Socket: LGA 1700
• Memory Type: DDR5
• Processor Family: Intel
