RAM Memory Kingston KVR32N22S8/8 8 GB DDR4 DIMM 3200 MHz CL22

The Kingston RAM memory KVR32N22S8/8 is a 8 GB DDR4 module designed to provide reliable and stable expansion for compatible desktop computers and PC/server systems. It comes in a 1 x 8 GB format with a 288-pin DIMM interface, making it easy to install on motherboards that support this standard slot type. It runs at 3200 MHz, delivering solid performance in multitasking and memory‑intensive applications, and features CL22 latency, suitable for work setups and home PCs. This module is Non-ECC, so it is mainly intended for personal computers and workstations that do not require memory error correction. It operates at a low 1.2 V voltage, helping reduce power consumption and heat generation compared to previous memory generations. Its black and green DIMM design is compatible with most current desktop motherboards, and is suitable for PC/Server systems that accept standard DDR4. In addition, it complies with RoHS regulations and is free of halogens, in line with current environmental standards. Backed by Kingston’s experience in memory solutions, this KVR32N22S8/8 module is a solid and stable option for upgrading or expanding a computer’s memory capacity in a simple and safe way.

• Type:
  • Memory (RAM)
  • DDR4
• Recommended use: PC/Server
• Supported memory speed: 3200 mhz
• Width: 133,3 mm
• Connections:
  • 288-pin DIMM
  • DIMM
• Voltage:
  • 1.2 V
  • 1,2 V
  • 2,5 V
• Colour:
  • Black
  • Green
• Capacity: 8 GB
• RAM Memory: 8 GB RAM
• Speed: 3200 MHz
• Certificate: RoHS
• Memory Type:
  • DDR4
  • DIMM
• Form factor:
  • 288-pin DIMM
  • RDIMM
• Compatible:
  • Computers
  • PC/Server
• Latency: CL22
• Does not contain: Halogen
• Format: 1 x 8 GB

ValueRAM's KVR32N22S8/8 is a 1G x 64-bit (8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx8, memory module, based on eight 1G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.

• Internal memory: 8 GB
• Memory layout (modules x size): 1 x 8 GB
• Internal memory type: DDR4
• Memory clock speed: 3200 MHz
• Component for: PC/server
• Memory form factor: 288-pin DIMM
• ECC: N
• Buffered memory type: Unregistered (unbuffered)
• CAS latency: 22
• Memory ranking: 1
• Memory voltage: 1.2 V
• Module configuration: 1024M x 64
• Row cycle time: 45.75 ns
• Refresh row cycle time: 350 ns
• Row active time: 32 ns
• Programming power voltage (VPP): 2.5 V
• Lead plating: Gold
• JEDEC standard: Y
• Operating temperature (T-T): 0 - 85 °C
• Storage temperature (T-T): -55 - 100 °C
• Sustainability certificates: RoHS
• Doesn't contain: Halogen
• Width: 133.3 mm
• Height: 31.2 mm
