Desktop Switch D-Link GO-SW-16G

The desktop switch D-Link GO-SW-16G is an unmanaged switch designed for small offices, workspaces and advanced home networks that need to expand wired connectivity with simple, stable installation. It includes 16 RJ45 ports with 10/100/1000 Mbps Ethernet LAN support, allowing connection of computers, network printers, NAS or other compatible devices and making full use of gigabit connections for fast, smooth data transfer. Its chassis combines a metal structure with plastic elements, offering good resistance and durability in typical work environments and an IP20 protection rating suitable for indoor use. The compact size of approximately 23.1 x 15.8 x 4.6 cm, with the option for 1U installation, makes it easy to place on a desk, in cabinets or in tight spaces, and its design available in white or black blends discreetly with other network equipment. It operates with a 12 V / 1 A adapter and has a maximum power consumption of about 9 W, contributing to efficient operation, while the front LED status indicators let you check at a glance the status of each port and overall network activity. The device is designed to operate in a wide temperature range, approximately from -40 ºC to 70 ºC and between 10% and 90% non-condensing humidity, adding reliability in technical rooms with limited climate control. It includes the power adapter required for immediate start-up and is intended to run stably without advanced configuration, providing a practical solution to expand a gigabit network with standard structured cabling. Overall, the D-Link GO-SW-16G is positioned as a robust, versatile gigabit desktop switch to easily increase connection capacity in small and medium-sized networks.

• Approx. dimensions: 23,1 x 15,8 x 4,6 cm
• Energy consumption: 9 W
• Light indicator: LED
• Type:
  • Tablecloth
  • Switch
• Material:
  • Plastic
  • Metal
• AC input voltage: 12 V
• Speed:
  • 1 Gbps
  • 32 Gbps
  • 10/100/1000 Mbps
• Characteristics:
  • LED
  • Easy to set up
  • RoHS
  • LED indicator
  • LED in operation indicator
• Connections:
  • RJ45 x 16
  • RJ45
  • Ethernet LAN
• Connectivity:
  • Gigabit Ethernet
  • Ethernet LAN
• Technology: 1000Base-T
• Standard: IEEE 802.1p Class of Service (CoS) prioritization
• Feeding dish included: Yes
• Cable length: 110 cm
• Certificate:
  • BSMI
  • CB
  • LVD
• Height: 4,4 cm
• Width: 28 cm
• Length: 12,6 cm
• Approx. weight: 870 G
• Colour:
  • White
  • Black
• Voltage: 12 V
• Ports: 16
• IP rating: IP20
• Operating System: RouterOS
• Amperage: 1 A
• Power: 9 W
• Working range for humidity: 10 % - 90 %
• Power supply: Iincluded
• Form factor: 1U
• Approx. temperature: -40º / 70º
• Units: 4 Units

The GO-SW-16G/24G 16/24‑Port Gigabit Easy Desktop Switch is an economical, plug-and-play networking switch solution for SOHO and small and medium businesses wanting to benefit from the increased bandwidth of Gigabit Ethernet. It provides 16 or 24 10/100/1000 Mbps ports that enable you to easily expand your network and provide a quick way to upgrade your network to fast connectivity.The GO-SW-16G/24G 16/24‑Port Gigabit Easy Desktop Switch is an economical, plug-and-play networking switch solution for SOHO and small and medium businesses wanting to benefit from the increased bandwidth of Gigabit Ethernet. It provides 16 or 24 10/100/1000 Mbps ports that enable you to easily expand your network and provide a quick way to upgrade your network to fast connectivity.Upgrade to Gigabit NetworkingWith data transfer speeds of up to 2000 Mbps at full-duplex, this switch is ideal for quick file transfers, online gaming, and smooth streaming media. It features easy-to-access Ethernet ports with LED indicators per port to easily distinguish link status. Auto-MDI/MDIX crossover makes connections a cinch just plug in your cables and you are ready to go.Conserve EnergyThe GO-SW-16G/24G supports IEEE 802.3az Energy-Efficient Ethernet, which saves energy and reduces heat automatically without sacrificing performance or functionality. The switch can detect when a connected computer is shut down or when there is no Ethernet traffic and can automatically reduce the power used for that port, cutting power usage substantially. In addition, the switch optimises power usage for each port based on the length of cable connected to it, using only as much power as is required. Both of these features work together to help you save power automatically.Reliable Plug and Play InstallationThe GO-SW-16G/24G is a plug-and-play device that requires no configuration, so setup is simple and hassle-free, and you can easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multiplayer gaming environment. IEEE 802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full, giving you a more reliable connection for all of your connected devices.

• Switch type: Unmanaged
• Switch layer: L2
• Quality of Service (QoS) support: Y
• Basic switching RJ-45 Ethernet ports quantity: 16
• Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
• Gigabit Ethernet (copper) ports quantity: 16
• Power connector: DC-in jack
• Networking standards: IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x
• 10G support: N
• Copper ethernet cabling technology: 1000BASE-T,100BASE-TX,10BASE-T
• Full duplex: Y
• Half duplex: Y
• Flow control support: Y
• Auto MDI/MDI-X: Y
• Ethernet LAN data rates: 10,100,1000 Mbit/s
• Auto-negotiation: Y
• MAC address table: 8000 entries
• Switching capacity: 32 Gbit/s
• Forwarding rate: 23.81 Mpps
• Store-and-forward: Y
• Number of queues: 8
• Jumbo frames support: Y
• Jumbo frames: 9216
• Packet buffer memory: 0.512 MB
• Rack mounting: Y
• Form factor: 1U
• Product colour: Black
• Housing material: Metal
• LED indicators: Y
• Certification: CE Class A, FCC Class A, VCCI Class A, BSMI, CCCUL, CB, LVD, BSMI, CCC
• Mean time between failures (MTBF): 305171 h
• Shipping (inner) case height: 38.4 cm
• Shipping (inner) case width: 34 cm
• Shipping (inner) case length: 56.9 cm
• Shipping (inner) case net weight: 15 kg
• Products per shipping (inner) case: 10 pc(s)
• Pallet gross weight (air): 491.5 kg
• Master (outer) cases per pallet (air): 30 pc(s)
• Products per pallet (air): 300 pc(s)
• Pallet gross length: 110 cm
• Pallet gross width: 120 cm
• Pallet height (air): 2.06 m
• Pallet gross weight (sea): 491.5 kg
• Master (outer) cases per pallet (sea): 30 pc(s)
• Products per pallet (sea): 300 pc(s)
• Pallet height (sea): 2.06 m
• Shipping (inner) case gross weight: 15.6 kg
• Power supply included: Y
• Redundant power supply (RPS) support: N
• Number of power supply units: 1
• DC input voltage: 12 V
• Input current: 1 A
• Power consumption (max): 11.7 W
• Power over Ethernet (PoE): N
• Operating temperature (T-T): 0 - 40 °C
• Storage temperature (T-T): -40 - 70 °C
• Operating relative humidity (H-H): 10 - 90%
• Storage relative humidity (H-H): 5 - 95%
• Heat dissipation: 39.92 BTU/h
• Width: 280 mm
• Depth: 126 mm
• Height: 44 mm
• Weight: 870 g
• Package width: 180 mm
• Package depth: 328 mm
• Package height: 108 mm
• Package weight: 1.45 kg
